Siemens simovert masterdrives

Parameter
Description Data Read/write
n832
Vis.DispAddMod 2
2832
Visualization parameter (KK 867)
Output of displacement adder 2 with limitation to ACL [LU]
32 bit
[Function diagram 794a]
Dec.Plc.: 0
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
U833*
ACL DisplAdd_2
2833
Axis cycle length for displacement adder 2
[Function diagram 794a]
Init: 4096
Min: 0
Max:
2147483647
Unit: -
Indices: -
Type: O4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U834*
S.DisplAdd_3
2834
Input of modulo displacement adder 3
[Function diagram 794a]
index1: 0
Unit: -
Indices: 4
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n835
Vis.DispAddMod_3
2835
Visualization parameter (KK 868)
Output of displacement adder 3 with limitation to ACL [LU]
32 bit
[Function diagram 794a]
Dec.Plc.: 0
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
U836*
ACL DisplAdd_3
2836
Axis cycle length for displacement adder 3
[Function diagram 794a]
Init: 4096
Min: 0
Max:
2147483647
Unit: -
Indices: -
Type: O4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U837*
Lower Uzk
2837
Range for voltage Uzk with reduced DC link voltage. Error
message F002 precharging is not triggered in this voltage
range. If the DC link voltage is lower than the value
parameterized in Index 2, binector B0856 goes high.
Index 1: Minimum Uzk with reduced DC link voltage.
Index 2: Maximum Uzk with reduced DC link voltage.
The value in Index 2 must always be greater than or equal
to the value in Index 1.
The function for operation with reduced DC link voltage is
active only if U838 = 1.
In the case of operation with reduced DC link voltage
(function diagram 501), the following is to be kept in mind.
Proper functioning of the braking chopper cannot be
guaranteed if the DC link voltage Uzk rises from the
reduced voltage range to the braking chopper turn-on
threshold in less than 3 s. Under such circumstances, the
chopper can fail to turn on and therefore trip out the
converter or inverter with fault F006 "Overvoltage".
index1: 380
Min: 10
Max: 510
Unit: V
Indices: 2
Type: O2
Menus:
- Parameter menu
+ Functions
- Drive setting
- Upread/free access
Changeable in:
- Drive setting
U838*
S.Sel.abg. Uzk
2838
Parameter for selection of a binector for reading in the
signal for releasing operation with reduced DC link voltage.
Init: 0
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
+ Functions
- Drive setting
- Upread/free access
Changeable in:
- Drive setting
- Ready to switch on
- Operation enabled
238
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
