Siemens simovert masterdrives

Parameter
Description Data Read/write
U840*
32BGear 1 ACL
2840
Axis cycle lengths of the 32-bit gear.
Index 1: Axis cycle length input
Index 2: Axis cycle length output
[Function diagram 786c]
index1: 4096
Min: 0
Max:
2147483647
Unit: -
Indices: 2
Type: O4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U841*
32BGear 1 VNorm
2841
Normalization of the 32-bit gear
Index 1: Normalization speed input
Index 2: Normalization speed output
[Function diagram 786c]
index1: 0,00
Min: 0,00
Max:
20000000,00
Unit: -
Indices: 2
Type: O4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U842*
S.32BGear1 Setp
2842
Setpoint sources of the 32-bit gear
Index 1: Distance setpoint input
Index 2: Speed setpoint input
Index 3: Setting value output
[Function diagram 786c]
index1: 0
Unit: -
Indices: 3
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U843*
S.32BGear 1 Trig
2843
Trigger input "Set output" of the 32-bit gear
[Function diagram 786c]
Init: 0
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U844*
S.32BGear1 Fact
2844
Factors of the 32-bit gear
Index 1: Numerator
Index 2: Denominator
[Function diagram 786c]
index1: 0
Unit: -
Indices: 2
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U845*
32BGear 2 ACL
2845
Axis cycle lengths of the 32-bit gear.
Index 1: Axis cycle length input
Index 2: Axis cycle length output
[Function diagram 786c]
index1: 4096
Min: 0
Max:
2147483647
Unit: -
Indices: 2
Type: O4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U846*
32BGear 2 VNorm
2846
Normalization of the 32-bit gear
Index 1: Normalization speed input
Index 2: Normalization speed output
[Function diagram 786c]
index1: 0,00
Min: 0,00
Max:
20000000,00
Unit: -
Indices: 2
Type: O4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U847*
S.32BGear 2 Setp
2847
Setpoint sources of the 32-bit gear
Index 1: Distance setpoint input
Index 2: Speed setpoint input
Index 3: Setting value output
[Function diagram 786c]
index1: 0
Unit: -
Indices: 3
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
239
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
