Siemens simovert masterdrives

Parameter
Description Data Read/write
U937*
Src SR CntrlSig
2937
Control signals of shift register
Index 1: Write clock shift register 1
L-H edge is switching edge
Index 2: Read clock shift register 1
L-H edge is switching edge
Index 3: Reset shift register 1
high active
Index 4: Reset multiplexer shift register 1
high active
Index 5: Shift direction shift register 1
0 = forwards
1= backwards
Index 6: Correction trigger shift register 1
L-H edge trips correction action
Index 7: Enable data shift register 1
0 = Output of P2936.3 at data output
1= Output of current dataset at data output
Index 1 - 7: [FD787a]
Index 8: Write clock shift register 2
L-H edge is switching edge
Index 9: Read clock shift register 2
L-H edge is switching edge
Index 10: Reset shift register 2
high active
Index 11: Reset multiplexer shift register 2
high active
Index 12: Shift direction shift register 2
0 = fowards
1= backwards
Index 13: Correction trigger shift register 2
L-H edge trips correction action
Index 14: Enable data shift register 2
0 = Output of P2936.6 at data output
1= Output of current dataset at data output
Index 8 - 14: [FD787b]
index1: 0
Unit: -
Indices: 14
Type: L2 ,B
Menus:
- Parameter menu
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n938
SR Status
2938
Visualization parameter status shift register
Index 1: Shift register 1 [FD787a]
Index 2: Shift register 2 [FD787b]
Dec.Plc.: 0
Unit: -
Indices: 2
Type: V2
Menus:
- Parameter menu
- Upread/free access
n939
SR OutputKK
2939
Visualization parameter connector output shift register
Index 1: Shift register 1 [FD787a]
Index 2: Shift register 2 [FD787b]
Dec.Plc.: 0
Unit: -
Indices: 2
Type: I4
Menus:
- Parameter menu
- Upread/free access
n940
SR1 RegisterKK
2940
Visualization parameter for connectors in dataset shift
register
n940: Shift register 1 [FD787a]
n942: Shift register 2 [FD787b]
Index 1: Dataset 01
Index 2: Dataset 02
...
Index 50: Dataset 50
Dec.Plc.: 0
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
n941
SR1 RegisterBi
2941
Visualization parameter for binectors in dataset shift
register
n941: Shift register 1 [FD787a]
n943: Shift register 2 [FD787b]
Index 1: Dataset 01
Index 2: Dataset 02
...
Index 50: Dataset 50
Dec.Plc.: 0
Unit: -
Indices: 50
Type: V2
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
252
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
