Connector number Connector name Description Double wordDSP
K0185 Isq(Deviation) System deviation of torque forming
current component.
In function diagram: 390.7, 389.7
no
yes
KK0186 Theta(I-Reg) Angle of rotation for vector rotation of
current control.
In function diagram: 390.7, 389.7
yes
yes
K0187 kT(ist) Actual value of conversion factor
torque <-> torque forming current
no
yes
K0188 n(slip) Slip speed.
In function diagram: 390.7, 389.7
no
yes
K0189 U(set,abs) Setpoint voltage amount from current
controller.
Phase-to-phase voltage, rms value of
the fundamental component. The
voltage applied to the motor is
reduced by the valve voltage.
In function diagram: 390.7, 389.7
no
yes
KK0200 f(set,V/f) Setpoint frequency v/f characteristic
in function diagram: 400.5
yes
yes
KK0201 Theta (V/f) Angle of rotation of v/f characteristic
In function diagram: 400.6
yes
yes
K0202 FSetp AddBoost Fixed setpoint for additional voltage
boost on v/f characteristic.
In function diagram: 400.2
no
no
K0203 Boost Voltage boost for v/f characteristic.
in function diagram: 400.4
no
no
K0204 U(set,V/f) Setpoint voltage for v/f characteristic
in function diagram: 400.7
no
yes
K0205 A(set,V/f) Setpoint modulation depth, v/f
characteristic
in function diagram: 400.8
no
yes
KK0206 n(set,V/f) Setpoint speed v/f characteristic.
in function diagram: 400.2
yes
yes
KK0207 f(set,V/f) 1 Reference frequency v/f characteristic
before intervention of I(max) controller.
in function diagram: 400.3
yes
yes
K0208 I max-Reg.(Out) Output I(max) controller for v/f
characteristic.
in function diagram: 400.3
no
yes
K0222 ModDepth (abs) Amount of modulation depth
in function diagram: 390.8, 420.7
no
yes
K0223 Switch-on Time1 Switch-on time 1
in function diagram: 420.6
no
yes
K0224 Switch-on Time2 Switch-on time 2
in function diagram: 420.6
no
yes
K0225 Switch-on Time3 Switch-on time 3
in function diagram: 420.6
no
yes
K0226 Usd(stp,smooth) For module test: voltage setpoint d-
component smoothed for display
no
yes
K0237 Usq(stp,smooth) For module test: voltage setpoint d-
component smoothed for display
no
yes
K0240 DC BusVolts act DC link voltage
in function diagram: 500.8
no
no
K0241 Torque(act) Torque actual value
In function diagram 390.2, 389.2
no
yes
K0242 OutputAmps(rms9 Fundamental frequenc rms value of
the output current
in function diagram: 500.7, 491.2
no
no
