Siemens simovert masterdrives

Connector number Connector name Description Double wordDSP
KK0160 n(DT1 Func)inv Inverted output of DT1 function on
DT1 function.
In function diagram: 360.5
yes
yes
KK0161 n-set(total) Total of the speed setpoints (function
diagram 360.4) or total of the speed
setpoints and the speed precontrol
value (function diagram 360a.5)
yes
yes
K0165 Torq(set,limit) Output connector torque limitation
In function diagram: 370.4
no
yes
K0166 Isq(set) Setpoint torque forming current
component after torque limitation and
conversion of torque -> current
In function diagram: 370.5
no
yes
K0167 Isq(set,limitr) Setpoint torque forming current
component after torque and current
limitation
in function diagram: 370.7
no
yes
K0168 Isq(set,active) Setpoint torque forming current
component from torque limitation to
current controller.
In function diagram: 370.8, 390.3,
389.3
no
yes
K0170 Torq(limit1,set Output of fixed setpoint for Torq(limit,1)
in function diagram: 370.1
no
yes
K0171 Torq(limit2,set Output of fixed setpoint for Torq(limit,
2)
in function diagram: 370.1
no
yes
K0172 Torq(limit1,act Upper torque limit of speed limitation
controller
in function diagram: 370.2
no
yes
K0173 Torq(limit2,act Lower torque limit of speed limitation
controller
in function diagram: 370.2
no
yes
K0175 Imax(perm) Currently valid value of maximum
current
in function diagram: 370.5
no
no
K0176 Isq(max, abs) Amount of torque forming current
component to which limitation takes
place in current limitation. The
maximum current and the magnetizing
current are included in calculation.
In function diagram: 370.6
no
yes
K0180 Psi(set) Fixed setpoint for setpoint flux
in function diagram: 390.1
no
yes
K0181 Psi(act) Actual value of flux calculated from
the flux model.
In function diagram: 390.7, 389.7
no
yes
K0182 Isd(act) Actual value of flux forming current
component (amplitude normalized to
reference current P350).
in function diagram: 390.4, 389.4
no
yes
K0183 Isd(set,active) Setpoint flux forming current (from flux
controller) (amplitude normalized to
reference current P350)
In function diagram: 390.4, 389.4
no
yes
K0184 Isq(act) Actual value of torque forming current
component (amplitude normalized to
reference current P350).
In function diagram: 390.4, 389.4
no
yes
6
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
