Siemens simovert masterdrives Compendium

Connector number Connector name Description Double wordDSP
K5212 AnaIn 2nd EB2 Setpoint, analog output of the second
inserted EB2
In function diagram: Y08.5
no
no
K5213 Stat.DI/DO 2EB2 Display of status of the terminals
(status of digital inputs/outputs) of the
second inserted EB2
In function diagram: Y08.3
no
no
K6001 ... K6016
not Compact PLUS
SCom2 Word Interface SCom2 no
no
KK6031 ... KK6045
not Compact PLUS
SCom2 DWord Interface 2 yes
no
K7001 ... K7016 SLB Word Setpoints
SIMOLINK
no
no
KK7031 ... KK7045 SLB DWord Setpoints
SIMOLINK
yes
no
K7081 Ind.Sync-Tgr Number of error-free synchronization
telegrams, corresponding to P748.1
In function diagram 140.8
no
no
K7082 Ind.CRC Error Number of CRC errors, corresponding
to P748.2 in function diagram
140.8
no
no
K7083 Ind.Timeout Number of timeout errors,
corresponding to P748.3 in function
diagram
140.8
no
no
K7085 NodeAddrTimeout Address of the node that sends the
"Time out" special telegram,
corresponding to P748.5 in function
diagram 140.8
no
no
K7089 SYNCDeviation Synchronicity deviation (65535
synchronization not active),
corresponding to P748.9 in function
diagram 140.8
no
no
K7091 T0 Counter T0 counter (0 with synchonization
active), corresponding to P748.11 in
function diagram 140.8
no
no
K7094 Time Counter Time slot counter, corresponding to
P748.14 in function diagram
140.8
no
no
K7101 ... K7108 SIMOLINK SpecD Special data from SIMOLINK no
no
KK7131 ... KK7137 SIMOLINK SpecD Special data from SIMOLINK yes
no
K8001 ... K8016 2 CB Word Setpoints for 2nd CB
In function diagram: 130.5
no
no
KK8031 ... KK8045 2 CB DWord Additional CB double-words
In function diagram: 130.6
yes
no
29
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
