Siemens simovert masterdrives Compendium

Binector list Motion Control
09.03.2010
Binector number Binector name Description
B0000 FixBinector 0 Fixed binector 0
In function diagram 15.2, 15.4
B0001 FixBinector 1 Fixed binector 1
In function diagram 15.4
B0005
not Compact PLUS
PMU ON/OFF Binector for input/output command via PMU
B0006
not Compact PLUS
PMU Pos Dir Binector for positive rotation direction via PMU
B0007
not Compact PLUS
PMU Neg Dir Binector for negative rotation direction via PMU
B0008 PMU MOP UP Binector for "Raise mot. potentiometer" via PMU
B0009 PMU MOP DOWN Binector for "Lower mot. potentiometer" via PMU
B0010 DigIn 1 Binary input (digital input) 1
In function diagram: 90.5
B0011 DigIn 1 inv. Binary input (digital input) 1 inverted
In function diagram: 90.5
B0012 DigIn 2 Binary input (digital input) 2
In function diagram: 90.5
B0013 DigIn 2 inv. Binary input (digital input) 2 inverted
In function diagram: 90.5
B0014 DigIn 3 Binary input (digital input) 3
In function diagram: 90.5
B0015 DigIn 3 inv. Binary input (digital input) 3 inverted
In function diagram: 90.5
B0016 DigIn 4 Binary input (digital input) 4
In function diagram: 90.5
B0017 DigIn 4 inv. Binary input (digital input) 4 inverted
In function diagram: 90.5
B0018 DigIn 5 Binary input (digital input) 5
B0019 DigIn 5 inv. Binary input (digital input) 5 inverted
B0020 DigIn 6 Binary input (digital input) 6
B0021 DigIn 6 inv. Binary input (digital input) 6 inverted
B0025 DigOut 1 Digital output 1
In function diagram: 90.6
B0026 DigOut 2 Digital output 2
In function diagram: 90.6
B0027 DigOut 3 Digital output 3
In function diagram: 90.6
B0028 DigOut 4 Digital output 4
In function diagram: 90.6
B0030 SCom1 TlgOFF Telegram failure at serial interface 1 (SCom1)
B0035 CB/TB TlgOFF TB/CB telegram failure
B0040 SLB TlgOFF SIMOLINK telegram failure
B0041 SIMOLINKTimeout This binector is set if timeout occurs on the
SIMOLINK ring. When communication functions
again, the binector is reset.
1
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
