Binector number Binector name Description
B0042 SIMOLINK Start This binector is set if no connection is realized on the
SIMOLINK ring. This usually means that the cable is
interrupted or a node is without supply voltage.
B0043 Drive Sync Binector indicates that the drive is synchronous
B0045 2.CB TlgOFF Telegram failure additional CB
B0047 SLB2 Timeout This binector is set when a timeout on the additional
non-active SIMOLINK ring (SLB2). When
communication is re-established, the binector is reset
again.
B0048 SLB2 start This binector is set when no connection is made on
the additional non-active SIMOLINK ring (SLB2). This
generally means that the line is interrupted or one of
the nodes is without supply voltage.
B0050
not Compact PLUS
SCB TlgOFF SCB telegram failure
B0055
not Compact PLUS
SCom2 TlgOFF SCom2 telegram failure
B0060 SBP CtrlTrack SBP control track
B0061 SBP RoughPulse1 SBP rough pulse 1
B0062 SBPRoughPulse2 SBP rough pulse 2
B0063 SBP FinePulse2 SBP fine pulse 2
B0065 SBPCtrlTrckMaEn SBP control track of the machine encoder
B0066 SBPRoughP1MaEn SBP rough pulse 1 from the machine encoder
B0067 SBPRoughP2MaEn SBP rough pulse 2 from the machine encoder
B0068 SBPFineP2MaEn SBP fine pulse 2 from the machine encoder
B0070 MeasV valid If this binector is 1, the position measured values are
applicable. During initialization or during any encoder
faults, the angles and the position values are not
applicable. Only when this binector is set, can the
angle or the position be evaluated. In the case of
resolvers, encoders and multiturn encoders, the
analog tracks are evaluated for monitoring.
B0071 MValValidMachEn If this binector is 1, the position measured values of
the machine encoder are valid. During initialization or
during any encoder faults in the encoder, the angle
and the position values are not applicable. Only when
this binector is set, can the angle or the position be
evaluated. In the case of resolvers, encoders and
multiturn encoders, the analog tracks are evaluated
for monitoring.
B0072 Zero pt acquird The zero point deviation shown on connector K0089 is
valid.
B0073 Z pt mach aqurd The zero point deviation of the external encoder
output on KK0088 is valid.
B0089 Status DTComp The binector indicates whether the dead time
compensation is enabled.
The relevant function is currently not yet implemented!
B0090 CalcTimeWarn Calculating time overload alarm
B0091 FaultCalcTime Calculating tme overflow fault
B0092 FDS Bit0 Function dataset bit 0
B0093 FDS Bit1 Function dataset bit 1
