Binector number Binector name Description
B0094 Fault ACK Corresponds to Control Word 1 Bit 7
function diagram 180.8
B0099 No n-Reg Enable Binector no speed controller enable
B0100 Rdy for ON "Ready for switching on" binector
B0101 Not Rdy for ON "NOT ready for switching on" binector
B0102 Rdy for Oper "Ready for operation" binector
B0103 NotRdy for Oper "NOT ready for operation" binector
B0104 Operation "Operation" binector
B0105 Not operating "Not operating" binector
B0106 Fault "Fault" binector
B0107 No fault "NO fault" binector
B0108 No OFF2 "NO OFF2" binector (low active!)
B0109 OFF2 "OFF2" binector (low active!)
B0110 No OFF3 "NO OFF3" binector (low active!)
B0111 OFF3 "OFF3" binector (low active!)
B0112 Blocked "Switch-on inhibit" binector
B0113 Not Blocked "NO switch-on inhibit" binector
B0114 Warning "Alarm active" binector
B0115 No Warning "NO alarm active" binector
B0116 No Deviation "No setpoint/actual value deviation" binector
B0117 Deviation "Setpoint/actual value deviation" binector
B0120 CompV OK "Comparison setpoint value achieved" binector
B0121 CompV not OK "Comparison setpoint value NOT achieved" binector
B0122 Low Voltage "Undervoltage" binector
B0123 No Low Voltage "NO undervoltage" binector
B0124 Energize MCon "Demand to energize main contactor" binector
B0125 N.Energ.MCon "Demand NOT to energize main contactor" binector
B0126 RampGen active "Ramp-function generator active" binector
B0127 RampGen n.act. "Ramp-function generator NOT active" binector
B0128 Speed Setp FWD "Positive speed setpoint" binector
B0129 Speed Setp REV "Negative speed setpoint" binector
B0132 Fly/Exc active "Flying restart or excitation active" binector
B0133 Fly/Exc n.act. "Flying restart or excitation NOT active" binector
B0136 Overspeed "Overspeed" binector
B0137 No Overspeed "NO overspeed" binector
B0138 Ext Fault 1 "External fault 1" binector
B0139 No Ext Fault 1 "NO external fault 1" binector
B0140 Ext Fault 2 "External fault 2" binector
3
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
