Binector number Binector name Description
B0897 SC_MINUS_ACTIV B0896: Stop cam Plus active
B0897: Stop cam Minus active
[In function diagram 789b.7/8]
B0910 ... B0913 DP V3 FCT G1 DP V3 G1_STW function 1-4 [in function diagram
172.7]
B910 = Bit 0 -> function1 G1_STW
B911 = Bit 1 -> function2 G1_STW
B912 = Bit 2 -> function3 G1_STW
B913 = Bit 3 -> function4 G1_STW
B0914 ... B0917 DP V3 FCT G2 DP V3 G2_STW function 1-4 [in function diagram
172.7]
B914 = Bit 0 -> function1 G1_STW
B915 = Bit 1 -> function2 G1_STW
B916 = Bit 2 -> function3 G1_STW
B917 = Bit 3 -> function4 G1_STW
B0918 DPV3 EnabRefM DP V3 Enable motor encoder referencing [in function
diagram 172.7]
B0919 DPV3 EnabRefE DP V3 Enable external encoder referencing [in
function diagram 172.7]
B0920 DPV3 SetRefPtM DP V3 Set motor encoder reference point [in function
diagram 172.7]
B0921 DPV3 SetRefPtE DP V3 Set external encoder reference point [in
function diagram 172.7]
B0922 DPV3 MovRefPtM DP V3 Displace motor encoder reference point [in
function diagram 172.7]
B0923 DPV3 MovRefPtE DP V3 Set external encoder reference point [in
function diagram 172.7]
B0924 DPV3 EnaMotMVM DP V3 Enable motor encoder measured value
memory [FP172.4]
B0925 DPV3 EnaExtMVM DP V3 Enable external encoder measured value
memory [FP172.4]
B0926 DPV3 Conf DIN4 DP V3 Configuration measured value memory for
digital input4 [FP172.4]
0=pos. edge
1=neg. edge
B0927 DPV3 Conf DIN5 DP V3 Configuration measured value memory for
digital input4 [FP172.4]
0=pos. edge
1=neg. edge
B0928 DPV3 Ack Fault DP V3 Fault acknowledgement MASTERDRIVES
[FP172]
B0929 DPV3 EN DIN4 DP V3 Enable measured value memory for digital
input4
Enable digital input DIN4 for the measured value
memory
[FP90.7]
B0930 DPV3 EN DIN5 DP V3 Enable measured value memory for digital
input5
Enable digital input DIN5 for the measured value
memory
[FP90.7]
B0931 DPV3 RoughTrig Encoder interface:
The rough pulse for the status machine SD6 (check
referencing) is triggered with the rough pulse trigger
for the referencing mode with zero pulse only. A rough
pulse is created in this case from the master via
status SD6.
B2100 ... B2115 SCom1Word1Bit USS Scom1 1st word
In function diagram: 60.1
16
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
