Siemens simovert masterdrives Compendium

Binector number Binector name Description
B0871 BPos_SET_REF Basic positioner set setpoint control signal
REF (enable referencing on the fly)
Function diagram 789a.7
B0872 BPos_SET_POS Basic positioner set setpoint control signal
POS (enable positioning)
Function diagram 789a.7
B0873 BPos_SET_SETUP Basic positioner set setpoint control signal
SETUP (enable setup)
Function diagram 789a.7
B0874 SET_POS_TYP_ACT Basic positioner set setpoint control signal
POS_TYP_ACT (valid positioner mode)
0=absolute
1=relative
Function diagram 789a.7
B0875 SET_D_FWD_ACT Basic positioner set setpoint control signal
D_FWD_ACT, (valid positive direction)
Function diagram 789a.7
B0876 SET_D_BWD_ACT Basic positioner set setpoint control signal
D_BED_ACT (valid negative direction)
Function diagram 789a.7
B0877 BPos_SET_PSR Basic positioner set setpoint control signal
PSR (positioning, setup, referencing)
Function diagram 789a.7
B0878 ... B0887 BPos FBin STW Fixed binector control word from U875.1 to U875.10
See function diagram 788a
B0888 BPos ARFD Basic positioner correction/referencing check-back
signal
ARFD (axis referenced)
Function diagram 789c.7
B0889 BPos Ref POV Basic positioner correction/referencing correction
signals
POV (positive overflow)
Function diagram 789c.7
B0890 BPos Ref NOV Basic positioner correction/referencing correction
signals
NOV (negative overflow)
Function diagram 789c.7
B0891 BPos Frg. IRQ Basic positioner correction/referencing control signal
Enable measured value memory
Function diagram 789c.7
B0892 BPos Window2 Basic positioner correction/referencing check-back
signals
F_REF_WD (print mark outside window2)
Function diagram 789c.5
B0893 REF_DRIVE [REF_DRIVE]
Homing has been selected and is active or not yet
finished.
B0894 BP SPV_RIE_ACKN Basic positioner transmit set setpoint
SPV_RIE_ACKN acknowledge transfer by SPV_RIE
when transfer triggered (SPV_RIE_TYP = 0)
Function diagram 789a.6
B0895 BPos SET REF_D Basic positioner set/setpoint block
REF enable direction
0=right
1=left
Function diagram 789a
B0896 SC_PLUS_ACTIV B0896: Stop cam Plus active
B0897: Stop cam Minus active
[In function diagram 789b.7/8]
15
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
