Binector number Binector name Description
B0835 B SLE active Simulink encoder active
B0836 Sync in F1 1 = synchronous in F2
The state of the synchronizing movement is
acknowledged by binectors (e.g. synchronizing speed
can thus be adjusted). The binector indicates that the
synchronizing difference is shown clearly in the
window.
B0837 Sync.in F2 1 = synchronous in F2
The state of the synchronizing movement is
acknowledged by binectors (e.g. synchronizing speed
can thus be adjusted). The binector indicates that the
synchronizing difference is shown clearly in the
window.
B0840 Positioning act Binector "Additive offset active"
In function diagram 794.8
B0850 BasicRFG1 POV Binector output of the 1st basic ramp generator (32
bit) for displaying the upper limit active.
[FP786a]
B0851 BasicRFG1 NOV Binector output of the 1st basic ramp generator (32
bit) for displaying the lower limit active.
[FP786a]
B0852 BasicRFG2 POV Binector output of the 2nd basic ramp generator (32
bit) for displaying the upper limit active.
[FP786b]
B0853 BasicRFG2 NOV Binector output of the 2nd basic ramp generator (32
bit) for displaying the lower limit active.
[FP786b]
B0856 Emerg/lowering Fixed binector 0
In function diagram 15.2, 15.4
B0858 Uzk>max lower Fixed binector 0
In function diagram 15.2, 15.4
B0859 Uzk< min lower Fixed binector 0
In function diagram 15.2, 15.4
B0860 BPos POS OK POS_OK (in window)
B0861 BPos POS_RUN POS_RUN (positioner running)
B0862 BPos RFG_RUN RFG_RUN (ramp generator running)
B0863 BPos RU_ACT RU_ACT (acceleration ramp active)
B0864 BPos RD_ACT RD_ACT (deceleration ramp active)
B0865 BPos FWD_RUN Status of individual positioning ramp generator
Axis running in positive direction
B0866 BPos BWD_RUN Status of individual positioning ramp generator
Axis running in negative direction
B0867 BPos POS_DELTA POS_REST (residual distance present)
B0868 BPos_SW_E_PLUS Basic positioner ramp function generator feedback
signal
SW_E_PLUS (software limit switch PLUS reached)
Function diagram 789b.8
B0869 BPos_SW_E_MINUS Basic positioner ramp function generator feedback
signal
SW_E_MINUS (software limit switch MINUS reached)
Function diagram 789b.8
B0870 SET_EN_POS_REF Basic positioner set setpoint control signal
ENABLE_POS_REF (enable basic positioner)
Function diagram 789a.7
14
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
