Binector number Binector name Description
B0826 ContSync Active The synchronism function can be temporarily
deactivated via disable/enable synchronism at U674.1
or by call-up in the mode manager. Previously internal
values/statuses of synchronism were reset in the
process.
If the new "Continue synchronism" function is
activated via binector input U674.2, internal
values/statuses are frozen. No internal reset of
values/statuses takes place. Thus during temporary
deactivation synchronism behaves as if it had never
been deactivated.
Thus the following statuses remain:
- Table remains, does not return to X0.0.
- Synchronous status remains.
- Referenced status remains.
- Engage/disengage coupled remains.
- Synchronization, offset angle setting [FD 841] are
continued.
- Position correction, referencing [FD 841] are
continued.
Binector 826 in function diagram 846 indicates
activation of the "Continue synchronism" function.
B0827 MastVCorVdifAct This binector is active during speed adjustment
between V% master value 1 at U451.5 and V%
master value 2, i.e. as long as the differential speed at
KK866 is not 0.
[In function diagram 845b.8]
B0828 Trig. MastV Cor Trigger master-value correction is used with the
master-value correction function during homing to
compensate for the actual-value jump. To this end,
this binector can be connected to "Trigger master-
value correction" B0828, and "Absolute value master-
value correction" KK0308 can be connected to
"Correction displacement" U453.
Function diagram: 817 (845)
B0829 Fault Ref. F2 Error in homing proximity switch (printing index)
outside window 2
B0830 MasterV Cor Act Fixed binector 0
In function diagram 15.2, 15.4
B0831 Ramp inactive Engage mode: (n658 = 1)
0: Engage/disengage ramping
1: Engage active and in constant travel
Disengage mode: (n658 = 2)
0: Disengage ramping
1: Disengage active and at standstill
Function diagram [834a.7, 834b.7, 834c.7]
B0832 Start active 1: Engage procedure active (ramp and constant travel)
0: Engaging action inactive
Function diagram [834a.7, 834b.7, 834c.7]
B0833 Stop active 1: Disengaging procedure active (ramp and constant
travel)
0: Disengaging inactive
Function diagram [834a.7, 834b.7, 834c.7]
B0834 Stop at tab end 1: Axis reached table function and table end
0: Table running, or no table function selected
13
