Binector number Binector name Description
B0811 Status Sync 0: No synchronization
1: Synchronization carried out
B0812 Backstop active 0: Backstop not active
1: Backstop active
The binector remains on 1 until the synchronize
master setpoint has been implemented.
B0813 Backstop n. act 0: Backstop active
1: Backstop not active
B0814 VarR_accepted Engage mode (n658 = 1) and disengage mode: (n658
= 2)
0: Change to Src. Variable Ramps not permitted
1: Change to Src.Variable Ramps permitted
Function diagram [834a.7, 834b.7, 834c.7]
B0815 RGen Active 1 = Speed ramp-function generator is active. V<>0
B0816 RGen RampAct 1 = Acceleration ramp of the speed ramp-function
generator is active. |X| > |V|
B0817 RGen_Setp OK 1 = Setpoint speed of the ramp-function generator has
been reached.
V=X
B0818 RGen A ACT 1 = Deceleration ramp of the speed ramp-function
generator is active.|X| < |V|
B0819 RGen_zero 1 = Output of the speed ramp-function generator is 0.
V=0
B0820 CatchUp_end Catch-up finished [CU_TE]
The catch-up function has been completed after
shutdown. The current speed has been reached and
synchronization to the master value can be softwired
to the synchronization master value (U676) via this
binector.
B0821 Stopping Pos ok Shutdown position reached [CU_PR]
The axis has been stopped and positioned. A different
function, e.g. pressure-plate change, can be initiated
in this position via this binector.
B0822 V CatchUp OK Catch-up speed reached [CU_VR]
The axis was set to stop, and the set catch-up speed
has been reached.
B0824 FB Release Ref Fixed binector for enabling referencing
B0825 FB Rel PosCorr Fixed binector for release of position correction
12
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
