Binector number Binector name Description
B0664 SWITCH B 1.65 4th digital switch
B0665 SWITCH B 1.96 5th digital switch
B0666 EXOR 0.93 1st EXOR element
B0667 EXOR 0.96 2nd EXOR element
B0668 EXOR 2.28 3rd EXOR element
B0669 ... B0676 SH 1.70 B Binectors of 3rd S&H Block
B0681 NAND 0.92 1st NAND element
B0682 NAND 1.24 2nd NAND element
B0683 NAND 1.47 3rd NAND element
B0684 NAND 1.95 4th NAND element
B0685 NAND 2.12 5th NAND element
B0686 NAND 2.27 6th NAND element
B0687 NAND 2.42 7th NAND element
B0688 NAND 2.94 8th NAND element
B0690 Plot FricChar Recording of friction characteristic finished
B0800 tg_Cor_Status Is set while correction of position setpoint is active
B0801 AccRampActive Engage mode: (n658 = 1)
0: Acceleration ramp inactive
1: Engage action is accelerating along ramp
Disengage mode: (n658 = 2)
0: Acceleration ramp inactive
1: Disengage action is accelerating along ramp
Function diagram [834a.7, 834b.7, 834c.7]
B0802 DecelRampActive Start mode: (n658 = 1)
0: Deceleration ramp inactive
1: Engage action is decelerating along ramp
Stop mode: (n658 = 2)
0: Deceleration ramp inactive
1: Disengage action is decelerating along ramp
Function diagram [[834a.7, 834b.7, 834c.7]
B0803 Start/Stop 1 = Engage/disengage active
during the duration of ramp and constant travel
0 = Engage/disengage inactive
Function diagram [834a.7, 834b.7, 834c.7]
B0804 TG_Mode 1 Fixed binector, operating mode "Start"
B0805 TG_Mode 2 Fixed binector, operating mode "Stop"
B0806 TG_Function1 Fixed binector gearbox function
B0807 TG_Function2 Fixed binector table function
B0808 Status Homing 0: Axis is not homed
1: Axis is homed
B0809 Status Home_inv 0: Axis is homed
1: Axis is not homed
B0810 Stat_Dis_An_cor 0: No correction
1: Displacement angle correction active
11
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
