Siemens simovert masterdrives

Binector number Binector name Description
B0608 AND 1.61 8th AND element
B0609 AND 1.62 9th AND element
B0610 AND 1.79 10th AND element
B0611 AND 1.80 11th AND element
B0612 AND 1.92 12th AND element
B0613 AND 2.26 13th AND element
B0614 AND 2.39 14th AND element
B0615 AND 2.51 15th AND element
B0616 AND 2.52 16th AND element
B0617 AND 2.54 17th AND element
B0618 AND 2.92 18th AND element
B0619 OR 0.90 1st OR element
B0620 OR 0.91 2nd OR element
B0621 OR 1.23 3rd OR element
B0622 OR 1.45 4th OR element
B0623 OR 1.63 5th OR element
B0624 OR 1.81 6th OR element
B0625 OR 1.93 7th OR element
B0626 OR 2.10 8th OR element
B0627 OR 2.11 9th OR element
B0628 OR 2.40 10th OR element
B0629 OR 2.70 11th OR element
B0630 OR 2.93 12th OR element
B0631 ... B0638 SH 1.68 B Binectors of 1st S&H Block
B0641 INVERTER 1.08 1st inverter
B0642 INVERTER 1.10 2nd inverter
B0643 INVERTER 1.11 3rd inverter
B0644 INVERTER 1.37 4th inverter
B0645 INVERTER 1.46 5th inverter
B0646 INVERTER 1.64 6th inverter
B0647 INVERTER 1.94 7th inverter
B0648 INVERTER 2.41 8th inverter
B0649 INVERTER 2.53 9th inverter
B0650 INVERTER 2.55 10th inverter
B0651 ... B0658 SH 1.69 B Binectors of 2nd S&H Block
B0661 SWITCH B 0.94 1st digital switch
B0662 SWITCH B 0.97 2nd digital switch
B0663 SWITCH B 1.48 3rd digital switch
10
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
