Binector number Binector name Description
B0561 ... B0568 TraceTriggerOut Fixed binector 0
In function diagram 15.2, 15.4
B0570 SampTimeChB0.66 Binary output signal of the 1st sampling time changer
B0571 SampTimeChB0.67 Binary output signal of the 2nd sampling time changer
B0572 SampTimeChB0.68 Binary output signal of the 3rd sampling time changer
B0573 SampTimeChB0.69 Binary output signal of the 4th sampling time changer
B0574 SampTimeChB0.70 Binary output signal of the 5th sampling time changer
B0575 SampTimeChB0.71 Binary output signal of the 6th sampling time changer
B0576 PulsGen1 B 0.65 Binary output signal of the 1st pulse generator
B0577 I32 OG B 1.53 Flag for output value at upper limit of the 1st integrator
B0578 I32 UG B 1.53 Flag for output value at lower limit of the 1st integrator
B0579 I32 OG B 1.85 Flag for output value at upper limit of the 2nd integrator
B0580 I32 UG B 1.85 Flag for output value at lower limit of the 2nd integrator
B0581 RealMaster P OV Binector for indicating a positive overflow of the input
value
B0582 RealMaster N OV Binector for indicating a negative overflow of the input
value
B0585 ErrorTrackMg This binector indicates that the motor encoder position
tracking has detected an overflow. This overflow
occurs when the permissible range of encoder
overflows with a linear axis has been exceeded
(U813.2).
In function diagram: 327.4
B0586 ErrorTrackEg
B0587 ... B0594 SR2 OutputBi Data input binectors shift register
B0492 - B0499: Shift register 1 [FD787a]
B0587 - B0594: Shift register 2 [FD787b]
B0595 ... B0596 SR MemDpthFull Shift register filled with data
B0595: Shift register 1 [FD787a]
B0596: Shift register 2 [FD787b]
B0597 ... B0598 SR MemDpthOverf Overflow or underflow, memory depth run through
once
B0597: Shift register 1 [FD787a]
B0598: Shift register 2 [FD787b]
B0599 ... B0600 SR MemDpthZero Current memory depth zero
B0599: Shift register 1 [FD787a]
B0600: Shift register 2 [FD787b]
B0601 AND 0.78 1st AND element
B0602 AND 0.79 2nd AND element
B0603 AND 0.89 3rd AND element
B0604 AND 1.09 4th AND element
B0605 AND 1.22 5th AND element
B0606 AND 1.35 6th AND element
B0607 AND 1.44 7th AND element
9
