Binector number Binector name Description
B0492 ... B0499 SR1 OutputBi Data input binectors shift register
B0492 - B0499: Shift register 1 [FD787a]
B0587 - B0594: Shift register 2 [FD787b]
B0501 ... B0502 RS-FF 1.34 1st RS flipflop 1: Q and Q_transv
B0503 ... B0504 RS-FF 1.36 2nd RS flipflop
B0505 ... B0506 RS-FF 1.49 3rd RS flipflop
B0507 ... B0508 RS-FF 1.66 4th RS flipflop
B0509 ... B0510 RS-FF 1.82 5th RS flipflop
B0511 ... B0512 RS-FF 1.97 6th RS flipflop
B0513 ... B0514 RS-FF 1.98 7th RS flipflop
B0515 ... B0516 RS-FF 2.13 8th RS flipflop
B0517 ... B0518 RS-FF 2.14 9th RS flipflop
B0519 ... B0520 RS-FF 2.29 10th RS flipflop
B0521 ... B0522 RS-FF 2.30 11th RS flipflop
B0523 ... B0524 RS-FF 2.71 12th RS flipflop
B0525 ... B0526 D-FF 1.25 1st D FF
B0527 ... B0528 D-FF 2.15 2nd D FF
B0530 ... B0531 TIMER 0.95 1st timer
B0532 ... B0533 TIMER 1.67 2nd timer
B0534 ... B0535 TIMER 1.84 3rd timer
B0536 ... B0537 TIMER 1.99 4th timer
B0538 ... B0539 TIMER 1.83 5th timer
B0540 ... B0541 TIMER 2.16 6th timer
B0542 ... B0543 TIMER 1.50 7th timer
B0544 ... B0548 ConnToParChkbk Checkback for connector-parameter converter
0=No memory access
1=Memory access necessary
B0550 ComfRGen Out=0 Output of the comfort ramp-function generator is zero
B0551 ComfRGen (y=x) Acceleration/deceleration of the comfort ramp-function
generator is finished (y=x)
B0552 ComfRGen First Initial acceleration of comfort ramp-function generator
(low active)
B0553 PlausPosD [FD784b] Diameter calculator
Plausibility check in positive direction active
B0554 PlausNegD [FD784b] Diameter calculator
Plausibility check in negative direction active
B0555 TechCtrl lim Technology controller at output limitation
B0556 TechCtrl lock Technology controller inhibited
B0557 MaxLimitD [FP784b] Diameter calculator
Diameter actual-value has an upper limit
B0558 MinLimitD [FP784b] Diameter calculator Diameter actual-value
has a lower limit
B0560 Wobb Slave-Sync Synchronizing signal for slave
