Binector number Binector name Description
B0361 Axis Home Technology option binector
Positioning status signals "Axis is referenced"
In function diagram 811.3
B0362 T Change Fixed binector 0
In function diagram 15.2, 15.4
B0363 Brake closed Demand from the positioning to close the brake.
B0370 ... B0385 C->B CONV5 16 binectors of the 5th connector -> binector converter
B0386 E2toRAM_ready Service binector, for Siemens service personnel only
B0400 POWER ON POWER ON signal
B0401 FixBit U021 FB: 1st fixed bit
B0402 FixBit U022 FB: 2nd fixed bit
B0403 FixBit U023 FB: 3rd fixed bit
B0404 FixBit U024 FB: 4th fixed bit
B0405 FixBit U025 FB: 5th fixed bit
B0406 FixBit U026 FB: 6th fixed bit
B0407 FixBit U027 FB: 7th fixed bit
B0408 FixBit U028 FB: 8th fixed bit
B0409 OFF&ActV OFF and shutdown threshold
Function diagram 480
B0410 ... B0425 K->B CONV1 16 binectors of the 1st connector -> binector converter
B0430 ... B0445 K->B CONV2 16 binectors of the 2nd connector -> binector converter
B0450 ... B0465 K->B CONV3 16 binectors of the 3rd connector -> binector converter
B0470 ... B0471 LIMITR B 1.74 1st limiter 16-bit
B0472 ... B0473 LIMITR B 2.38 2nd limiter 16-bit
B0474 ... B0475 LIMITR B 2.48 1st limiter 32-bit
B0476 LMTMON B 1.18 1st limit-value monitor: 16-bit
B0477 LMTMON B 2.49 2nd limit-value monitor: 16-bit
B0478 LMTMON B 2.68 3rd limit-value monitor: 32-bit
B0479 LMTMON B 1.75 4th limit-value monitor: 32-bit
B0480 ... B0481 CAMCON 0.60 Cam controller 1
B0482 ... B0483 CAMCON 0.61 Cam controller 2
B0484 ... B0485 CAMCONTR 0.80 Binector outputs
Cam controller 3
B0486 ... B0487 SR CorrAck Acknowledgement correction shift register
B0486: Shift register 1 [FD787a]
B0487: Shift register 2 [FD787b]
B0488 ... B0489 SR ResetAck Acknowledgement reset shift register
B0488: Shift register 1 [FD787a]
B0489: Shift register 2 [FD787b]
B0490 ... B0491 COUNTER 1.36 B 16-bit counter: positive overflow and negative overflow
7
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
