Binector number Binector name Description
B0291 DC volts < thr DC link bus voltage is less than the parameterizable
threshold
B0296 Vd(max)Reg act. The Vd(max controller is active
B0302 Set Pos P Control signal for setting the position actual-value
detection
B0303 Pos Corr'n PosP Control signal to the position actual-value detection for
correcting the position in positive direction
B0304 PosCorr'nNegP Control signal to the position actual-value detection for
correcting the position in negative direction
B0305 Rel Ctrl P Control signal for the position actual-value detection
for changing over to the operating mode "Control", i.e.
the position control is inhibited.
B0306 PosCorrPos Ext Correct position + external encoder
B0307 Rel Ref P Control signal to the position actual-value detection for
enabling referencing
B0308 Rel MValMem P Control signal to the position actual-value detection for
enabling the measured value memory
B0311 QuickOutp1 P Quick output of positioning. The significance is
determined with MD47 and MD48 (U501.47 and 48)
B0312 QuickOutp2 P Quick output of positioning. The significance is
determined with MD47 and MD48 (U501.47 and 48)
B0313 QuickOutp3 P Quick output of positioning. The significance is
determined with MD47 and MD48 (U501.47 and 48)
B0314 QuickOutp4 P Quick output of positioning. The significance is
determined with MD47 and MD48 (U501.47 and 48)
B0315 FastOutp5.P Fixed binector 0
In function diagram 15.2, 15.4
B0316 FastOutp6.P Fixed binector 0
In function diagram 15.2, 15.4
B0330 Simulation Binector simulation
B0350 FaultTechnolog Fixed binector 0
In function diagram 15.2, 15.4
B0351 ToggleBitOutp Fixed binector 0
In function diagram 15.2, 15.4
B0352 DwellTimeActive Fixed binector 0
In function diagram 15.2, 15.4
B0353 StartEnab Outp Fixed binector 0
In function diagram 15.2, 15.4
B0354 Process Runs Fixed binector 0
In function diagram 15.2, 15.4
B0355 Pos Reached Fixed binector 0
In function diagram 15.2, 15.4
B0356 Axis FWD Fixed binector 0
In function diagram 15.2, 15.4
B0357 Axis BWD Fixed binector 0
In function diagram 15.2, 15.4
B0358 Function End Fixed binector 0
In function diagram 15.2, 15.4
B0359 SW LimitSwitch Fixed binector 0
In function diagram 15.2, 15.4
B0360 Vir Master act. Fixed binector 0
In function diagram 15.2, 15.4
6
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
