Parameterizing Steps 08.2012
6SE7087-6QX70 (Version AN) Siemens AG
6-14 Compendium Motion Control SIMOVERT MASTERDRIVES
Board Significance Parameter value
CUVC Control Unit Vector Control 92
CUMC Control Unit Motion Control 93
CUMC+ Motion Control Compact PLUS 94
CUVC+ Control Unit Vector Control Compact PLUS 95
CUPM Control Unit Motion Control Performance 2 96
CUMP
Control Unit Motion Control Compact PLUS
Performance 2
97
CUSA Control Unit Sinus AFE 108
SBP Sensor Board Pulse 111
SBM Sensor Board Encoder / Multiturn 112
SBM2 Sensor Board Encoder / Multiturn 2 113
SBR1 Sensor Board Resolver 1 114
SBR2 Sensor Board Resolver 2 115
SCB1
Serial Communication Board 1 (fiber-optic
cable)
121
SCB2 Serial Communication Board 2 122
T100 Technology board 131
T300 Technology board 131
T400 Technology board 134
CBX Communication Board 14x
CBP Communication Board PROFIBUS 143
CBD Communication Board DeviceNet 145
CBC Communication Board CAN Bus 146
CBL Communication Board CC-Link 147
CBP2 Communication Board PROFIBUS 2 148
EB1 Expansion Board 1 151
EB2 Expansion Board 2 152
SLB SIMOLINK bus interface 161
