P367 = ?
Select type of control
0: V/f open-loop control
2: Torque control
3: Speed control
P368 = ?
Select setpoint and command source
0: PMU (not for Compact PLUS)
1: Analog input and terminal strip
2: Fixed setpoints and terminal strip
3: MOP and terminal strip
4: USS
5: not used
6: PROFIBUS (CBP2)
7: OP1S and fixed setpoints via SCom1
8: OP1S and MOP via SCom1
4
Input the USS address
Input the PROFIBUS address
P368 =
0, 1, 2, 3
P918.1 = ?
P700.1 = ?
6
7, 8
P370 = 1
P060 = 0
Return to user menu
Start of quick parameterization
0: No parameter change
1: Parameter change according to chosen
combination of parameter modules
Note:
After start-up an automatic factory setting of P366 = 0
takes place, followed by the associated parameterization.
Parameterizing with parameter modules is carried out only in BICO
data set 1 and in function data set 1.
If data set changeover is required, you will have to carry out a further
detailed parameterization using parameter modules after having
performed quick parameterization.
Quick parameterization is effected in the "Download" converter status.
