SIMOVERT MASTERDRIVES Compendium Motion Control 8.1-15
Reply ID Meaning
0 No reply
1 Transfer parameter value (word)
2 Transfer parameter value (double word)
3 Transfer descriptive element
1
4 Transfer parameter value (array, word)
2
5 Transfer parameter value (array, double word)
2
6 Transfer the number of array elements
7 Task cannot be executed (with error number)
8 No control/change rights for the PKW interface
9 Parameter change report (word)
10 Parameter change report (double word)
11 Parameter change report (array, word)
2
12 Parameter change report (array, double word)
2
13 Reserved
14 Reserved
15 Transfer text
* For table footnotes
1
and
2
, see Table 8.1-5
Table 8.1-6 Reply IDs (drive converter -> master)
Source for the ON/OFF1 command (control word1, bit 0):
P554 (=22A hex) Change parameter value (array, word) and save in
the EEPROM.
Parameter ID (PKE)
1st word
Bit No.: 15 12 11 10 0
AK SPM PNU
1 1 0 0 0 0 1 0 0 0 1 0 1 0 1 0 Binary value
C 2 2 A HEX value
♦ Bits 12 to 15: Value = 12 (= "C" hex); change parameter value (array, word) and save
in the EEPROM
♦ Bits 0 to 11: Value = 554 (= "22A" hex); parameter number with a set change-report
bit
Example
