SIMOVERT MASTERDRIVES Compendium Motion Control 8.1-21
In the SIMOVERT MASTERDRIVES MC series, the control electronics
board, CUMC (Control Unit Motion Control), CUPM (Control Unit
Motion Control Performance 2), CUMP (Control Unit Motion Control
Compact PLUS Performance 2), CUVC (Control Unit Vector Control) or
CUVP (Control Unit Vector Control Compact PLUS) is used. Depending
on the type of basic unit, it has at least one serial interface with the
USS protocol. The following table shows the available interfaces:
Board Number of interfaces Physical interface Baud rate
[kBit/s]
CUPM in Compact and
chassis type unit
2 interfaces with USS
protocol
Designation: SCom1
and SCom2
RS485 / 2-wire on terminal strip X103
(SCom1 and SCom2)
or
RS232 or RS485 / 2-wire at 9-pole SUB-D
socket X300 (SCom1)
max. 38.4
CUMP in
Compact PLUS unit
1 interface with USS
protocol
Designation: SCom1
RS485 / 2-wire at terminal strip X100
or
RS232 or RS485 / 2-wire at 9-pole SUB-D
socket X103
max. 38.4
CUMC in
Compact PLUS unit
1 interface with USS
protocol
Designation: SCom1
RS485 / 2-wire at terminal strip X100
or
RS232 or RS485 / 2-wire at 9-pole SUB-D
socket X103
max. 38.4
CUMC in Compact and
chassis type unit
2 interfaces with USS
protocol
Designation: SCom1
and SCom2
RS485 / 2-wire on terminal strip X103
(SCom1 and SCom2)
or
RS232 or RS485 / 2-wire at 9-pole SUB-D
socket X300 (SCom1)
max. 38.4
CUVC in Compact and
chassis type unit
2 interfaces with USS
protocol
Designation: SCom1
and SCom2
RS485 / 2-wire on terminal strip X101
(SCom2)
and
RS232 or RS485 / 2-wire at 9-pole SUB-D
socket X300 (SCom1)
max. 38.4
CUVP in
Compact PLUS unit
2 interfaces with USS
protocol
Designation: SCom1
and SCom2
RS485 / 2-wire on terminal strip X100
(SCom2)
and
RS232 (SCom1) or RS485 / 2-wire
(SCom2) at 9-pole SUB-D socket X103
max. 38.4
Table 8.1-9 Interfaces on the CU board
All the interfaces on the CU boards are non floating (not electrically
isolated).
The SCB2 (Serial Communications Board) is an expansion board of the
SIMOVERT MASTERDRIVES. The board has a floating RS485
interface. Either the peer-to-peer protocol or the USS protocol can be
used at this interface.
The supplementary SCB2 board cannot be built into the Compact
PLUS type of unit.
Basic unit with
CUMC/CUPM/
CUVC/CUVP
NOTICE
SCB 2
supplementary
board
NOTE
