Siemens simovert masterdrives Compendium

Communication / USS 02.2004
6SE7087-6QX70 (Version AD) Siemens AG
8.1-22 Compendium Motion Control SIMOVERT MASTERDRIVES
Board Number of interfaces Physical interface
SCB2
1 interface with
USS protocol
RS485 / 2-wire at
terminal strip X128
Table 8.1-10 Interface on the SCB 2 board
For a more detailed description of the SCB 2, refer to the instruction
manual, "Serial Communication Board 2"
(Order No.: 6SE7087-6CX84-0BD0).
The T100 technology board is an expansion board of the SIMOVERT
MASTERDRIVES. The board has two, non-floating RS485 interfaces.
One interface is permanently provided for the peer-to-peer protocol, the
other is for the USS protocol.
The T100 technology board cannot be built into the Compact PLUS
type of unit.
Board Number of interfaces Physical interface
T100
1 interface with USS protocol
and
1 interface for peer-to-peer linking
RS485 / 2-wire at
terminal strip X132
Table 8.1-11 Interfaces on the T100 board
For a more detailed description of the T100, refer to the instruction
manual "Technology Board T100" [Order No. 6SE7080-0CX87-0BB0,
(hardware) and 6SE7080-0CX84-0BB0 (software)].
The CBP2 interface board (Communication Board PROFIBUS 2) is an
extension board of the SIMOVERT MASTERDRIVES. The board has a
floating RS485 interface. For this interface, either the PROFIBUS
protocol or the USS protocol can be used.
Board Number of interfaces Physical interface
CBP2
1 interface with
USS protocol
RS485 / 2-wire at
terminal strip X448
Table 8.1-12 Interface on the CBP2 board
A more detailed description of the CBP2 can be found in the operating
instructions "CBP/CBP2 - Communication Board PROFIBUS" (Order
No.: 6SE7087-6NX84-0FF0).
NOTE
T100 technology
board
NOTE
NOTE
CBP2
supplementary
board
NOTE
