Siemens simovert masterdrives Compendium

Communication / USS 02.2004
6SE7087-6QX70 (Version AD) Siemens AG
8.1-42 Compendium Motion Control SIMOVERT MASTERDRIVES
The two status words 1 (bits 0 to 15) and 2 (bits 16 to 31) send
messages from the converter to a higher-level converter system.
An indexed parameter is assigned to each interface. Each index is
assigned to a net-data word in the PZD area. For example, index i001
to the 1st word, index i002 to the 2nd word and so on up to i016.
Parameter
number
Parameter Index and value
(index i001 for BICO data set 1)
(index i002 for BICO data set 2)
SCom1
707 (SCom1 actual
values)
i001 to 016
SCom2
(not with the
Compact PLUS)
708 (SCom2 actual
values)
i001 to 016
SCB2 706 (SCB actual values) i001 to 016
Status word 1 is always transferred in the 1st word of the PZD area in
the USS protocol.
"Interconnection" of status word 1 and the actual speed/frequency
(KK0091) at interface SCom1.
♦ Precondition:
PZD area at least 2 words in length; P703, i001 ≥ 2 is set.
Parameter
No.
Parameter Index and value Comments
P707
SCom1 actual
values
i001 = 0032
1st word in the PZD area:
status word (K0032)
i002 = 0091
2nd word in the PZD area:
actual speed/frequency (KK0091, only H-Word)
i003 to i016 = 0
3rd to 16th word in the PZD area (if parameterized):
"Not interconnected"
"Interconnection" of
status words 1 and 2
and the actual
values
NOTE
Example 1
