02.2004 Communication / USS
Siemens AG 6SE7087-6QX70 (Version AD)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.1-43
"Interconnection" of status word 1, status word 2, actual speed
(KK0091) and the actual DC link voltage (K0240) at the interface on
SCB2.
♦ Precondition:
PZD area at least 5 words in length; P703, i003 ≥ 5 is set.
Parameter
number
Parameter Index and value Comments
P706
SCB actual
values
i001 = 0032
1st word in the PZD area:
status word (K0032)
i002 = 0091
2nd word in the PZD area:
high word of the actual speed (KK0091)
i003 = 0091
3rd word in the PZD area:
low word of the actual speed (KK0091)
i004 = 0033
4th word in the PZD area:
status word 2 (K0033)
i005 = 0240
5th word in the PZD area:
Vd(act) (K0240)
When 32-bit quantities are being transferred, the high word is located in
PZD n, the low word in PZD n+1.
→ For example, 32-bit actual value of KK0091 in PZD2 and PZD3.
Example 2
NOTE
