Communication / PROFIBUS 09.2008
6SE7087-6QX70 (Version AK) Siemens AG
8.2-20 Compendium Motion Control SIMOVERT MASTERDRIVES
Reply ID Significance
0 No reply
1 Transfer parameter value (word)
2 Transfer parameter value (double word)
3 Transfer description element
1
4 Transfer parameter value (array, word)
2
5 Transfer parameter value (array, double word)
2
6 Transfer the number of array elements
7 Task cannot be executed (with error number)
8 No operator change rights for the PKW interface
9 Parameter change report (word)
10 Parameter change report (double word)
11 Parameter change report (array, word)
2
12 Parameter change report (array, double word)
2
13 Reserved
14 Reserved
15 Transfer text (not with CBP)
1
The required element of the parameter description is specified in IND (2nd word)
2
The required element of the indexed parameter is specified in IND (2nd word)
Table 8.2-5 Reply IDs (converter -> master)
Source for the ON/OFF1 command (control word 1, bit 0):
P554 (=22A Hex)
Change parameter value (array, word) and store in the EEPROM
Parameter ID (PKE) 1
st
word
Bit No.: 15 12 11 10 0
AK SPM PNU
1 1 0 0 0 0 1 0 0 0 1 0 1 0 1 0 Binary value
C 2 2 A HEX value
♦ Bits 12 to 15: Value = 12 (= "C" Hex); change parameter value (array,
word) and store in the EEPROM
♦ Bits 0 to 11: Value = 554 (= "22A" Hex); parameter number without
set bit for the parameter change report
Example
