Communication / PROFIBUS 09.2008
6SE7087-6QX70 (Version AK) Siemens AG
8.2-126 Compendium Motion Control SIMOVERT MASTERDRIVES
Bits remain set until the next DP global control.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Bit
♦ Bit 0 Reserved
♦ Bit 1 1 = Clear_Data telegram received
♦ Bit 2 1 = Unfreeze telegram received
♦ Bit 3 1 = Freeze telegram received
♦ Bit 4 1 = Unsync telegram received
♦ Bit 5 1 = Sync telegram received
♦ Bits 6,7 Reserved
Counter for telegrams received error-free (only DP standard)
Counter for received DP net telegrams
Counter TIMEOUT
Counter is incremented if the "TIMEOUT" signal is identified.
This occurs if, for example, the bus connector is pulled out when
response-monitoring has been activated (at the DP master).
Counter CLEAR DATA
Is incremented if the global ctrl. signal "CLEAR DATA" is identified (see
also r732.3). This occurs if, for example, the DP master is set in "STOP".
Counter Heartbeat-Counter Error
Is incremented if the heartbeart-counter is not changed by the basic
board or the technology board within approx. 800 ms.
Number of bytes during special diagnosis
Number of bytes entered after r732.9 during special diagnosis selected
by means of CB parameter 1.
Mirroring slot Identifier 2
Read out of the DPRAM during run up: Offset Address 054H, with VC,FC
and SC, corresponds to parameter P090.
Mirroring slot Identifier 3
Read out of the DPRAM during run up: Offset Address 055H, with VC,FC
and SC, corresponds to parameter P091.
Mirroring P918
Read out of the DPRAM during run up: "CB Bus address" (only Low-
byte)
Counter Re-configuration by CU
Re-configuration requested by the basic board in online mode
Counter Initialization
Is incremented during run through of the initialization routine
DPS Manager Error
Error detection in the event of a fatal DPS manager error
PPO type
PPO type detected from configuration telegram
Reserved
Mirroring "DWORD-Specifier-ref"
Read out of the DPRAM during run up: updated cyclically
Mirroring "DWORD-Specifier-act
Read out of the DPRAM during run up: updated cyclically
r732.3 (094H,
Global_Controls)
r732.4
(Low-Byte), 096H
r732.5
(Low-Byte), 098H
r732.6
(Low-Byte), 09AH
r732.7
(Low-Byte), 09CH
r732.8
(Low-Byte), 09EH
r732.9
(Low-Byte), 0A0H
r732.9
(High-Byte), 0A1H
r732.10
(Low-Byte), 0A2H
r732.11
(Low-Byte), 0A4H
r732.11
(High-Byte), 0A5H
r732.12
(Low Byte), 0A6H
r732.13
(Low-Byte), 0A8H
r732.13
(High-Byte), 0A9H
r732.14,
0AAH u. 0ABH
r732.15,
0ACH u. 0ADH
