SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-129
P711
P696
= 0 No supplementary diagnosis (default setting)
The following entries apply to cyclical data transfer via MSZY-C1
P711
P696
= 1
PPO useful data in the
CBP receive buffer
Useful-data telegram
(master → converter)
Length depends on PPO
type
P711
P696
= 2
PPO useful data in the
CBP transmit buffer
Useful-data telegram
(converter → master)
Length depends on PPO
type
P711
P696
= 3 Configuration buffer
Useful-data telegram
(master → converter)
Length = 25 bytes
P711
P696
= 4 Parameterization buffer
Parameterization
telegram
(master
→ converter)
Length = 10 bytes
The following entries apply to cyclical data transfer via MSAC-C1
P711
P696
= 10 Useful data of the DS100
Data unit in DS_WRITE
to DS100
Max. 32 bytes
P711
P696
= 11 Useful data of the DS100
Data unit in DS_READ to
DS100
Max. 32 bytes
The following entries apply to acyclical data transfer via MSAC-C2
P711
P696
= 21 Useful data in the DB99
Data unit in PUT to the
DB99
Max. 32 bytes
P711
P696
= 22 Useful data in the DB99 Data unit in GET to DB99 Max. 32 bytes
P711
P696
= 23 Useful data in the DB100
Data unit in PUT to
DB100
Max. 32 bytes
P711
P696
= 24 Useful data in the DB100
Data unit in GET to
DB100
Max. 32 bytes
P711
P696
= 25 Useful data in the DB101
Data unit in PUT to
DB101
Max. 32 bytes
P711
P696
= 26 Useful data in the DB101
Data unit in GET to
DB101
Max. 32 bytes
Table 8.2-28 Selection of PROFIBUS-DP telegram entries
