SIMOVERT MASTERDRIVES Compendium Motion Control 8.4-35
P711 (CB parameter 1) P696 (CB parameter 1)
Basic identifier for PKW task (parameter task)
With this parameter, the basic identifier can be set for a PKW task (parameter
task). The actual CAN identifier for a PKW task is calculated from this
parameter and the node address (P918) according to the following equation:
(Parameter value of P711/ P696) + (Parameter value of P918)*2
The CAN identifier for a PKW reply (parameter reply) is the number
subsequent to this, namely
(Parameter value of P711/ P696) + (Parameter value of P918) *2 + 1
With the value 0 (pre-assigned) in this parameter, parameterization via the
CAN bus is deactivated.
If the calculated CAN identifier for the PKW task or PKW reply is outside the
valid range (1 to 2000) or if it overlaps another CAN identifier, error F080
appears when status 4 "hardware configuration" is left. After
acknowledgement of the error, you are in the "hardware configuration" status
again and can correct the incorrect parameterization.
Example:
The basic identifier for parameterization in P711 / P696 is set to 1500. The
node address in P918 is 50. The CAN identifier is thus 1500 + 50*2 = 1600
for a PKW task and 1601 for a PKW reply.
