02.2004 Communication / CBC CANopen Communication Board
Siemens AG 6SE7087-6QX70 (Version AD)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.5-9
Transmitted by
SDO
Transmitted by
PDO
Object
index
Sub-
index
Object
name
Description
Yes /
No
Connector /
Parameter
Yes /
No
Connector /
Parameter
3012h Free object 3012h / 16
Bit
Free 16-bit object for
receiving in PDO 2,3,4
Yes
2
5
10
Yes K3007
K3011
K3015
3013h Free object 3013h / 16
Bit
Free 16-bit object for
receiving in PDO 2,3,4
Yes
2
5
10
Yes K3008
K3012
K3016
3014h Free object 3014h / 16
Bit
Free 16-bit object for
receiving in PDO 2,3,4
Yes
2
5
10
Yes K3008
K3012
K3016
3015h Free object 3015h / 16
Bit
Free 16-bit object for
receiving in PDO 2,3,4
Yes
2
5
11
Yes K3005
K3009
K3013
3016h Free object 3016h / 16
Bit
Free 16-bit object for
receiving in PDO 2,3,4
Yes
2
5
11
Yes K3006
K3010
K3014
3017h Free object 3017h / 16
Bit
Free 16-bit object for
receiving in PDO 2,3,4
Yes
2
5
11
Yes K3007
K3011
K3015
3018h Free object 3018h / 16
Bit
Free 16-bit object for
receiving in PDO 2,3,4
Yes
2
5
11
Yes K3008
K3012
K3016
3020h Free object 3020h / 32
Bit
Free 32-bit object for
receiving in PDO 1
Yes
2
5
9
10
11
Yes K3033
3021h Free object 3021h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
9
10
Yes K3037
K3041
K3045
3022h Free object 3022h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
9
10
Yes K3037
K3041
K3045
3023h Free object 3023h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
9
10
Yes K3037
K3041
K3045
3024h Free object 3024h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
9
10
11
Yes K3035
K3039
K3043
3025h Free object 3025h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
9
10
11
Yes K3037
K3041
K3045
3026h Free object 3026h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
9
10
11
Yes K3035
K3039
K3043
3027h Free object 3027h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
9
10
11
Yes K3037
K3041
K3045
3028h Free object 3028h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
10
Yes K3036
K3040
K3044
3029h Free object 3029h / 32
Bit
Free 32-bit object for
receiving in PDO 2,3,4
Yes
2
5
11
Yes K3035
K3039
K3043
