Siemens simovert masterdrives Compendium

02.2004 Communication / CBC CANopen Communication Board
Siemens AG 6SE7087-6QX70 (Version AD)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.5-45
T_PDO
No.
Mapping
object
index
Mapping object
name
DPR
parameter
T_PDO
number
in DPR
T_PDO
identifier
When selected
enter in
parameters
44 3125h
Free object
3125h 32 Bit
P734.05/.06
P734.09/.10
P734.13/.14
2
3
4
280h+NodeID
380h+NodeID
480h+NodeID
716
717
718
45
3125h
310Dh
Free object
3125h 32 Bit
Free object
310Dh 16 Bit
P734.05/.06
P734.09/.10
P734.13/.14
P734.07
P734.11
P734.15
2
3
4
280h+NodeID
380h+NodeID
480h+NodeID
716
717
718
46
3125h
310Dh
310Eh
Free object
3125h 32 Bit
Free object
310Dh 16 Bit
Free object
310Eh 16 Bit
P734.05/.06
P734.09/.10
P734.13/.14
P734.07
P734.11
P734.15
P734.08
P734.12
P734.16
2
3
4
280h+NodeID
380h+NodeID
480h+NodeID
716
717
718
47
3125h
3126h
Free object
3125h 32 Bit
Free object
3126h 32 Bit
P734.05/.06
P734.09/.10
P734.13/.14
P734.07/.08
P734.11/.12
P734.15/.16
2
3
4
280h+NodeID
380h+NodeID
480h+NodeID
716
717
718
48
2
6077h
310Fh
Torque actual value
P734.5
P734.9
P734.13
2
3
4
280h+NodeID
380h+NodeID
480h+NodeID
716
717
718
49
2
6077h
310Fh
Torque actual value
Free object 310F 16
Bit
P734.5
P734.9
P734.13
P734.6
P734.10
P734.14
2
3
4
280h+NodeID
380h+NodeID
480h+NodeID
716
717
718
50
2
6077h
310Fh
3110h
Torque actual value
Free object
310F 16 Bit
Free object
3110 16 Bit
P734.5
P734.9
P734.13
P734.6
P734.10
P734.14
P734.7
P734.11
P734.15
2
3
4
280h+NodeID
380h+NodeID
480h+NodeID
716
717
718
