02.2004 Communication / CBC CANopen Communication Board
Siemens AG 6SE7087-6QX70 (Version AD)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.5-51
Table of error values
No. Meaning
0 Illegal parameter number (PNU) If no PNU is connected at all
1 Parameter value cannot be changed If the parameter is a visualization parameter
2 Lower or upper value limit exceeded -
3 Errored subindex -
4 Not an array
In response to tasks for indexed parameters addressed to
a nonindexed parameter.
E.g. task: "Change parameter value (word, array)" for
nonindexed parameter
5 Incorrect data type -
6 Setting not allowed (resetting only) -
7 Description element cannot be changed Task cannot be executed on MASTERDRIVES
11 No control command source status -
12 Keyword missing
Device parameter: "Access key" and/or "Par. special
access" not appropriately set
15 Text array does not exist -
17
Task cannot be executed in current
operating state
Current converter status prohibits execution of transmitted
task
101 Parameter number currently deactivated -
102 Channel not wide enough
1)
Parameter response too long for CAN message
103 Incorrect number of PKWs Error cannot occur on CBC
104 Illegal parameter value
2)
-
105 The parameter is indexed
In response to tasks for nonindexed parameters
addressed to an indexed parameter.
E.g. task: "Change PWE word" for indexed parameter
106 Task not implemented -
107 Text cannot be changed -
108 Number of PWEs <> index number -
1)
This error number is transferred if the parameter response to a parameter task is
longer than the available 8 bytes of CAN data message which means that it
cannot be sent. The data are not divided up between data messages.
2)
This error number is transferred if no function is assigned in the device to the
parameter to be passed or if it cannot currently be accepted for internal reasons
(although it is within legal limits).
