Siemens simovert masterdrives Compendium

Communication / CBC CANopen Communication Board 02.2004
6SE7087-6QX70 (Version AD) Siemens AG
8.5-58 Compendium Motion Control SIMOVERT MASTERDRIVES
Error code
(hex)
Meaning MC error MC alarm Error text /
description
FF00 external fault 1 F035 External fault 1
FF01 external fault 2 F036 External fault 2
FF02 PIN is missing F063 PIN missing
FF03 Fault 1 Function blocks F148 Fault 1 function blocks
FF04 Fault 2 Function blocks F149 Fault 2 function blocks
FF05 Fault 3 Function blocks F150 Fault 3 function blocks
FF06 Fault 4 Function blocks F151 Fault 4 function blocks
FF07 SIMOLINK start Alarm A002 SIMOLINK startup alarm
FF08 Drive not synchronous A003 Drive not synchronous
FF09 Simulation active alarm A014 Simulation active alarm
FF10 External alarm 1 A015 External alarm 1
FF11 External alarm 2 A016 External alarm 2
FF12 Alarm 1 Function blocks A061 Alarm 1 function blocks
FF13 Alarm 2 Function blocks A062 Alarm 2 function blocks
FF14 Alarm 3 Function blocks A063 Alarm 3 function blocks
FF15 Alarm 4 Function blocks A064 Alarm 4 function blocks
FF16
Axis does not exist machine
data 1=0
A129
Axis does not exist, machine
data 1=0
FF17
Operating conditions do not
exist
A130
Operating conditions not
fulfilled
FF18 OFF1 Missing A131 OFF1 missing
FF19 OFF2 Missing A132 OFF2 missing
FF20 OFF3 Missing A133 OFF3 missing
FF21 Enable Controller ENC Missing A134 No controller enable ENC
FF22 Machine data 1 changed A136
Machine data 1 (position
encoder type) changed, RESET
necessary
FF23
Actual value disable not
allowed – axis stand still
A145
Actual value disabling illegal -
axis standstill
FF24
Direction of movement not
allowed
A146 Direction of movement illegal
FF25 Deceleration=0 A148 Deceleration=0
FF26 Distance to go negative A149 Distance to go negative
FF27 Setup speed=0 A160 Set up velocity stage=0
FF28 Reference approach velocity A161 Homing approach velocity=0
FF29 Reference point reducing=0 A162 Homing creep velocity=0
FF30 MDI Block number not allowed A165 MDI travel block number illegal
