Example of variable point allocation among tables:
400 interpolation
points available
Table 1
80 interpolation
points from 1-80
Table 2
80 interpolation
points from
81-160
Table 3
80 interpolation
points from
161-240
Table 4
80 interpolation
points from
241-320
Table 5
80 interpolation
points from
321-400
Table 1
200 interpolation
points from 0-200
Table 2
100 interpolation
points from
201-300
Table 3
100 interpolation
points from
301-400
Example 1 Example 2
