Siemens simovert masterdrives

Function diagram
87654321
fp_mc_111_e.vsd
USS/SCom2
MASTERDRIVES MC
22.10.02
Transmitting
-111 -
V2.5
PKW
processing
PKW
words
PcD
words
16
2
3
4
6
5
7
8
9
10
11
12
13
14
15
16
PKW Word 1 USS SCom 2
PKW Word 2 USS SCom 2
PKW Word 4 USS SCom 2
PKW Word 3 USS SCom 2
.01
.02
.03
.04
.05
.06
.07
.08
.09
.10
.11
.12
.13
.14
.15
.16
Transmit
Transmitting 32-bit words:
If the same double-word connector is connected up to two successive connector
indices, this is transferred as a 32 bit word.
Examples:
2.
1.
KK1000 is transferred as
a 32-bit word
.02
.03
Only the high part of
KK1000 and KK2000 is
transferred as a 16-bit word
.02
.03
.04
TxD
Transmit telegram
TLG
End
15 14
PcD
3 2 1
TLG HeadPKW
1
Not valid for Compact PLUS
K
P708 (0)
SrcSCom2TrnsData
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
SCom2Trns/RecvData
r710.17 to .32
PKW Reply
r739.13 to .16
1000
P708 (0)
1000
KK1000
KK1000
2000
P708 (0)
1000
KK2000
KK1000
900KK0900
U950.24 = ___(4)
