A.3 Temperature sensors for SINAMICS components
Commissioning with Startdrive
380 Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
Component
Interface
Pin
Signal name
Technical specifications
TM150
X531 1
2
3
4
+Temp
-Temp
+Temp
-Temp
KTY84-1C130/PTC/bimetallic NC
contact/PT100/PT1000
Information on interconnecting the
temperature channels can be
found below
X532 1
2
3
4
+Temp
-Temp
+Temp
-Temp
X533 1
2
3
4
+Temp
-Temp
+Temp
-Temp
X534 1
2
3
4
+Temp
-Temp
+Temp
-Temp
X535 1
2
3
4
+Temp
-Temp
+Temp
-Temp
X536 1
2
3
4
+Temp
-Temp
+Temp
-Temp
SME20
Measuring system
interface
7
9
-Temp
+Temp
Temperature sensor
KTY84-1C130 / PTC
connection cable with article num-
ber 6FX8002-2CA88-.... neces-
sary
1)
SME120/SME125
X200 (connector)
Temperature chan-
nel 2
1
2
-Temp
+Temp
Temperature sensor
KTY84-
1C130/PTC/PT1000/bimetallic
switch with NC contact
X200 (connector)
Temperature chan-
nel 3
3
4
+Temp
-Temp
Temperature sensor
KTY84-
1C130/PTC/PT1000/bimetallic
switch with NC contact
X200 (connector)
Temperature chan-
nel 4
5
6
+Temp
-Temp
Temperature sensor
KTY84-
1C130/PTC/PT1000/bimetallic
switch with NC contact
Active Line Module
Booksize
X21 (terminal)
1
2
+Temp
-Temp
Active Line Module temperature
sensor
Temperature switch type: bimetal-
lic switch with NC contact
Chassis
X41 (terminal)
4
3
+Temp
-Temp
Smart Line Module
Booksize
X21 (terminal)
1
2
+Temp
-Temp
Active Line Module temperature
sensor
Temperature switch type: bimetal-
lic switch with NC contact
Chassis
X41 (terminal)
4
3
+Temp
-Temp
