MA2 All fields are adjusted irrespective of the configured field sizes.
PA Optimized and pixel-precise stretching of the fields for higher resolutions
(Pixel Fine Adjustment)
Previously all field positions were calculated in relation to 640x480 and then
zoomed with the appropriate horizontal and vertical stretch factors. This
process has the disadvantage that rounding errors can occur with "unfav‐
orable stretch factors". For example, the field height or line spacing can
"jump" by a pixel from line-to-line. The "Pixel Fine Adjustment" mode can
be used to prevent this as the field positions are determined directly in the
current resolution.
//M(MyMask/"My Mask"/////PA1)
This setting can also be made globally for all Run MyScreens masks in the
easyscreen.ini, e.g.
[GENERAL]
DefaultPixelFineAdjustment=1
If the mask attribute PA is set explicitly in the mask configuration, it has a
higher priority than the global setting in the easyscreen.ini.
If a mask is displayed with Font Adjustment = FA1, then the Pixel Fine
Adjustment mode is also automatically active for this mask.
(See also Chapter SmartOperation and MultiTouch operation (Page 45))
PA0 Stretching as previously, i.e. the positions are calculated in relation to
640x480 and then stretched.
(For compatibility reasons: Default)
PA1 Optimized and pixel-precise stretching of the fields for higher resolutions
FA Field height and line spacing proportional to the font (Font Adjustment)
This setting can also be made globally for all Run MyScreens masks in the
easyscreen.ini, e.g.
[GENERAL]
DefaultFontAdjustment=1
If the mask attribute FA is set explicitly in the mask configuration, then this
has a higher priority than the global setting in easyscreen.ini.
The settings for the DefaultLineHeight and DefaultLineSpacing have no
significance when Font Adjustment mode is active.
(See also Chapter SmartOperation and MultiTouch operation (Page 45))
FA0 Field height and line spacing are stretched as previously. (For compatibility
reasons: Default)
FA1 Field height and line spacing are set proportional to the font (automatically
sets mask attribute PA=1)
FA2 Same as FA1, but the X coordinate and the field width are also stretched
proportionally to the font
(Automatically sets mask attribute PA=1)
(Only possible in conjunction with attribute XG=1!)
NT Navigation Type
NT0 NT0 = standard mode
The navigation is analogous to the masks of the operating area in which
Run MyScreens mask is integrated. This means in the cycle masks in the
editor, navigation is line-oriented (see NT2), in all other "normal" masks, it
is a geometrical (see NT1).
Dialogs
4.1 Structure and elements of a dialog
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 53
