Icon (optional) icon for display in the machining step program, format
Screen size for corresponding resolution:
640 X 480 mm → 16 x 16 pixels
800 X 600 mm → 20 x 20 pixels
1024 X 768 mm → 26 x 26 pixels
1280 X 1024 mm → 26 x 26 pixels
1280 X 768 mm → 26 x 26 pixels
Archive:
[system user directory]
/ico/ico<resolution>
Notes:
● For resolutions of 1280, the folder for 1024 x 768 mm is used
(only suitable for machining step programs).
● The screen size is not just dependent on the resolution, but also
on the font size set in the editor.
Desc_Text (optional) Explanation text for display in the machining step pro‐
gram, max. length of string is 17 characters (only suitable for ma‐
chining step programs).
Param_Text (optional) Text for the parameter list
T=%1 D=%2
Note
Notes on Icon, Desc_Text and Param_Text:
1. The user icon is always displayed in the G code editor. The G code icon is always displayed
in the ShopMill/ShopTurn editor. This helps to better distinguish between ShopMill/
ShopTurn steps and NON-ShopMill/ShopTurn steps.
2. The Run MyScreens step is dependent on the editor setting "Display cycles as machining
step". This applies to both the G code and the JobShop editor.
This means that when "Display cycles as machining step" = "YES", the "Desc_Text" of the
Run MyScreens configuration is taken; when "NO", the cycle is displayed.
3. Desc_Text and Param_Text
– can be specified according to language via the $xxxxx notation.
– The parameters of the cycle call generated can be accessed via %1, %2, etc. This
involves the placeholder being replaced by the parameter that is specified after the '%'
in the parameter list generated.
Example
//M(TestGC/"Code generation:")
DEF VAR1 = (R//1)
DEF VAR2 = (R//2)
DEF D_NAME
LOAD
VAR1 = 123
Programming commands
6.3 Functions
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 179
