The result is written to register 0.
REG[0] = CallCWMethod("MyGraphVar", "setView", -8, -5, 11- 20)
Overview
Function Description
setView Sets coordinate system
setMaxContourObjects Sets maximum number of objects for a contour (ring buffer)
addContour Adds a contour
showContour Shows a contour
hideContour Hides a contour
hideAllContours Hides all contours
removeContour Removes a contour
clearContour Deletes graphic object of a contour
fitViewToContours Automatic adaptation of the view
fitViewToContour Automatic adaptation of the view
findX Searches in a contour
setPolylineMode Displays points of a contour as polyline/curve
setIntegralFillMode Displays points of a contour as polyline/curve
repaint, update Refreshes view
addPoint Adds a point to a contour
addLine Adds a line to a contour
addRect Adds a rectangle to a contour
addRoundedRect Adds a rectangle with rounded corners to a contour
addEllipse Adds an ellipse to a contour
addCircle Adds a circle to a contour
addArc Adds an arc to a contour
addText Adds text to a contour
setPenWidth Sets the pen width
setPenStyle Sets the pen style
setPenColor Sets the pen color
setFillColor Sets fill color
setCursorPosition Positions the cursor
setCursorPositionY2 Positions the cursor referred to the second Y axis (right)
setCursorOnContour Positions the cursor on contour
moveCursorOnContourBegin Positions the cursor to the first graphic object of a contour
moveCursorOnContourEnd Positions the cursor to the last graphic object of a contour
moveCursorOnContourNext Positions the cursor to the next graphic object of a contour
serialize Saves/restores the actual state
