Enabling the graphic tool and magazine display function
Make the following settings when the tools and the magazine should be represented
graphically:
MD52271 $MCS_TM_MAG_PLACE_DISTANCE Distance between individual magazine lo‐
cations in the unit of measurement of the
basic NC system.
> 0 The tools and magazine locations are displayed graphically.
= 0 The tools and magazine locations are not displayed graphically.
You must make the following settings on the user interface:
1. Press the "Settings" softkey in the "Tool list" window.
The "Settings" window opens.
2. Activate the "Switch on graphical magazine display" checkbox.
This checkbox is offered only when the MD52271 $MCS_TM_MAG_PLACE_DISTANCE
machine data has a value > 0.
Supplementary conditions:
● MD52200 $MCS_TECHNOLOGY = 2 (milling)
● MD52201 $MCS_TECHNOLOGY_EXTENSION = 0
Default settings for unloading/loading and relocating
MD52272 $MCS_TM_TOOL_LOAD_DEFAULT_MAG Default magazine for loading tools.
= 0 No default magazine, default value
MD52273 $MCS_TM_TOOL_MOVE_DEFAULT_MAG Default magazine for relocating tools.
= 0 No default magazine, default value
MD52274 $MCS_TM_TOOL_LOAD_STATION Number of loading station.
= 0 All configured stations are considered, default value
Input limits for wear input
MD51212 $MNS_TM_WRITE_WEAR_ABS_LIMIT Maximum value of the tool wear.
MD51213 $MNS_TM_WRITE_WEAR_DELTA_LIMIT Maximum differential value of restricted tool
wear input.
MD51214 $MNS_TM_WRITE_LIMIT_MASK Range of validity of the restricted tool wear
input.
Tool management
12.1 Machine data for tool management
SINUMERIK Operate (IM9)
168 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
