Data of the control components
Control components Data
NC data Machine data
Setting data
Option data
Global (GUD) and local (LUD) user data
Tool and magazine data
Protection zone data
R parameters
Zero offsets
Workpieces, part programs and subprograms
Standard and user cycles
Definitions and macros
With compensation data
● QEC - quadrant error compensation
● CEC - operation/angularity compensation
● EEC - leadscrew pitch / encoder error compensation
It only makes sense to archive machine-specific compensation data
if the start-up file is reloaded into the same control.
With compile cycles Compile cycles (*.elf) are displayed, if compile cycles are available.
PLC data (including CP) OB (organization blocks)
FB (function blocks)
SFB (system function blocks)
FC (functions)
SFC (system functions)
DB (data blocks)
SDB (system data blocks)
Drive data Archiving the drive data, either in binary or ASCII format.
HMI data, all
HMI data, selection: If data is available, you must set the check mark to activate the
components.
Texts User texts, alarm texts
Templates Individual templates, workpiece templates
Applications HMI applications, OEM applications
Engineering data Engineering data
Configuration Configurations, incl. display of machine data
Help Help files
Version data Version data
Logs Error logs
Program lists Program lists
Dictionaries Dictionaries
Data backups Files located in the data tree of the "System data" in the "HMI data /
data backups" directory.
Programs on local drive Programs contained in the user memory area of the CompactFlash
card.
Data backup
16.2 Creating a start-up archive
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 357
