Control components Data
Comment Entry field for possible comments regarding the start-up archive.
Created by Entry field for the creator as well as creation date of the start-up
archive.
Procedure
1. Select the "Start-up" operating area.
2. Press the menu forward key.
3. Press the "Start-up archive" softkey.
The "Start-up" window opens.
4. Activate "Create a start-up archive" and press the "OK" softkey.
The "Create Start-up Archive" window opens.
5. Select the desired control components.
6. When required, enter a comment as well as your name and the date of
creation.
7. Press the "OK" softkey.
The "Generate Archive: Select Storage Location" window opens.
8. Position the cursor at the required storage location, press the "Search"
softkey and enter the required search term in the search dialog. Then
press the "OK" softkey if you wish to search for a certain directory or
subdirectory.
Note: The place holders "*" (replaces any character string) and "?" (re‐
places any character) make it easier for you to perform a search.
- OR -
Select the required storage location, press the "New directory" softkey,
enter the required name in the "New Directory" window and press the
"OK" softkey to create a directory.
9. Press the "OK" softkey.
The "Generate Archive: Name" window opens.
10. Enter the required name and press the "OK" softkey.
An archive file with the ARC format type is stored in the selected directory.
Data backup
16.2 Creating a start-up archive
SINUMERIK Operate (IM9)
358 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
