Availability of the network connections
Network adapter connection
White Network cable inserted
Red Network cable not inserted
Availability
The availability describes the percentage of faulty packages compared to all the sent and
received packages.
Problems in the company network (e.g. logical drives that cannot be accessed, double IP
address, etc.) as well as settling time during power up can result in fluctuations in availability.
Green Greater than 95%
Yellow 50 - 95%
Red Less than 50%
Details of the network connections
● Computer name
● DNS name
Computer name of the controller as stored at the DNS server (Domain Name Service).
● MAC address
Physical address of the network adapter
Configuring the network
17.6 Station-related network diagnostics
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 393
