Data set for the 2nd transformation in the channel
MD24200 $MC_TRAFO_TYPE_2
= 513 Transformer type (513 = cylinder surface transformation with groove side offset)
MD24210 $MC_TRAFO_AXES_IN_2
[0] = 3 Channel axis: Infeed axis perpendicular (radial) to rotary axis Z
[1] = 4 Channel axis: Rotary axis A
[2] = 1 Channel axis: 1st axis of the machining plane parallel to the rotary axis X
[3] = 2 Channel axis: 2nd axis of the machining plane Y
MD24220 $MC_TRAFO_GEOAX_ASSIGN_TAB_2
[0] = 1 Channel axis: 1st geometry axis X
[1] = 4 Channel axis: 2nd geometry axis A
[2] = 3 Channel axis: 3rd geometry axis Z
MD24850 $MC_TRACYL_ROT_AX_OFFSET_2
= 0 Offset of the rotary axis for the 2nd TRACYL transformation
MD24855 $MC_TRACYL_ROT_SIGN_IS_FRAME_2
= 1 Axial offset for the 2nd TRACYL transformation
MD24860 $MC_TRACYL_ROT_SIGN_IS_PLUS_2
= 1 Sign of the rotary axis for the 2nd TRACYL transformation
MD24870 $MC_TRACYL_BASE_TOOL[ ]
[0] = 0 Vector of the base tool for the 2nd TRACYL transformation in XYZ
[1] = 0
[2] = 0
Note
Data sets for transformations
For both data sets, you can use any transformations from all available transformations
(MD24100 $MC_TRAFO_TYPE_1, MD24200 $MC_TRAFO_TYPE_2, etc.). The two data sets
need not be directly next to each other.
However, the 1st data set must always be used for "Cylinder surface transformation without
groove side offset" (= 512) and the 2nd data set for "Cylinder surface transformation with
groove side offset" (=513).
