General settings for the transformation
MD10602 $MN_FRAME_GEOAX_CHANGE_MODE Frames when switching over geometry
screens
= 1 The actual total frame (zero offsets) is recalculated when switching over geometry axes (se‐
lecting - deselecting TRACYL).
Data set for the 1st transformation in the channel
MD24100 $MC_TRAFO_TYPE_1 Definition of transformation 1 in the chan‐
nel.
= 512 Transformer type (512 = cylinder surface transformation without groove side offset)
MD24110 $MC_TRAFO_AXES_IN_1 Axis assignment for the 1st transforma‐
tion in the channel
[0] = 3 Channel axis: Infeed axis (tool axis) perpendicular (radial) to the rotary axis Z
[1] = 4 Channel axis: Rotary axis A
[2] = 1 Channel axis: 1st axis of the machining plane parallel to the rotary axis X
[3] = 2 Channel axis: 2nd axis of the machining plane Y
MD24120 $MC_TRAFO_GEOAX_ASSIGN_TAB_1 Assignment of the geometry axes to chan‐
nel axes for transformation 1.
[0] = 1 Channel axis: 1st geometry axis X
[1] = 4 Channel axis: 2nd geometry axis A
[2] = 3 Channel axis: 3rd geometry axis Z
MD24800 $MC_TRACYL_ROT_AX_OFFSET_1
= 0 Offset of rotary axis for the 1st TRACYL transformation.
MD24805 $MC_TRACYL_ROT_AX_FRAME_1
= 1 Axial offset of rotary axis for the 1st TRACYL transformation.
MD24810 $MC_TRACYL_ROT_SIGN_IS_PLUS_1
= 1 Sign of the rotary axis for the 1st TRACYL transformation.
MD24820 $MC_TRACYL_BASE_TOOL_1[ ]
[0] = 0 Vector of the base tool for the 1st TRANSMIT transformation in XYZ
[1] = 0
[2] = 0
Technologies and cycles
21.4 Milling
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 525
