MD51226 $MNS_FUNCTION_MASK_SIM Simulation function screen
Bit 5 = 1 Turning tool in tool spindle rotatable (for simulation)
MD51781 $MNS_MEA_T_PROBE_THICKNESS Tool probe thickness for the automatic approach
of turning tools to the probe on milling/turning ma‐
chines
= 0 Default value
MD20100 $MC_DIAMETER_AX_DEF Geometry axis with transverse axis function
=X The machine data defines a geometry axis as transverse axis.
MD20110 $MC_RESET_MODE_MASK Definition of control initial setting after reset / end
of part program
Bit 0 = 1 Default value for system
MD20112 $MC_START_MODE_MASK Definition of the basic control setting after part pro‐
gram start
Bit 7 = 0 The current setting for the active transformation is retained.
MD20124 $MC_TOOL_MANAGEMENT_TOOL‐
HOLDER
Tool holder number
= 1 Variable
MD20125 $MC_CUTMOD_ERR Alarm display for CUTMOD errors
= CFFFH Display alarms for CUTMOD errors
MD20150 $MC_GCODE_RESET_VALUES[21] Initial setting of the G groups
= 2 Initial setting of G group 22 on CUT2DF
MD20150 $MC_GCODE_RESET_VALUES[55] Initial setting of the G groups
= 3 Initial setting of G group 56 TOWWCS
MD20152 $MC_GCODE_RESET_MODE[21] Reset behavior of the G groups
= 0 Reset behavior of G group 22
MD20152 $MC_GCODE_RESET_MODE[55] Reset behavior of the G groups
= 3 Reset behavior of G group 56 TOWWCS
Technologies and cycles
21.8 Turning on milling machines
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 599
