MD20360 $MC_TOOL_PARAMETER_DEF_MASK Definition of the tool parameters
Bit 17 = 0 With CUTMOD for turning and grinding tools, the cutting edge for the calculation of the
compensation values is not configured in the machining plane.
Bit 18 = 1 With CUTMOD for turning and grinding tools, always use the active plane for turning and
grinding tools.
MD21203 $MC_LIFTFAST_MODE_MASK Settings for fast lifting
Bit 0 = 1 This bit activates the monitoring of the direction for LIFTFAST for thread turning.
MD24030 $MC_FRAME_ACS_SET SZS coordinate system setting
= 1 SZS results from the WCS transformed with the $P_CYCFRAME
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET[ ] Reset behavior of the spindle
[Tool spindle] = 2 Do not stop tool spindle during jog → spindle is listed in the T,S,M screen
[Turning spindle] = 2 Do not stop turning spindle during jog → spindle is listed in the T,S,M
screen
MD52001 $MCS_DISP_COORDINATE_SYSTEM_2 Definition of the displayed directions in the user
interface for turning operations (variable)
= 0
MD52200 $MCS_TECHNOLOGY Technology
= 2 Milling
MD52201 $MCS_TECHNOLOGY_EXTENSION Extended technology
= 1 Turning
MD52206 $MCS_AXIS_USAGE[ ] Meaning of the axes in the channel
[Tool spindle] = 1 Tool spindle
[Turning spindle] = 3 Turning spindle
MD52207 $MCS_AXIS_USAGE_ATTRIB[turning spindle] Attributes of the axes
Bit 8 = 1 Offer rotary axis for blank clamping
MD52212 $MCS_FUNCTION_MASK_TECH General function screen for all technologies
Bit 10 = 1 Align the turning tool via kinematics transformation
Technologies and cycles
21.8 Turning on milling machines
SINUMERIK Operate (IM9)
600 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
