MD52214 $MCS_FUNCTION_MASK_MILL Milling function screen
Bit 1 = 1 Offer fixed table for blank clamping
Note
Only set bit 1 in MD52214 when a fixed table is used in addition to a rotary table.
MD52780 $MCS_J_MEA_T_PROBE_APPR_MO
DE
Approach mode for measuring a tool in JOG
= 0 Technology-dependent approaching of the tool probe (default value)
Turning technology: Manual approach
Milling technology: Automatic approach
= 1 Technology-independent approaching of the tool probe
Manual approaching of the tool probe
= 2 Technology-independent approaching of the tool probe
Automatic approaching of the tool probe
MD52242 $MCS_TURN_TOOL_FIXING Tool adapter for turning tools
= 0 Turning tools in tool spindle
= 1 Turning tools fixed on the tool headstock
= 2 Turning tools in the tool spindle or fixed on the tool headstock
Note
Depending on the set mounting alignment in MD52242, different parameters are available in
the "Align Turning Tool" dialog.
Setting data
The following setting data is recommended: Set the setting data to set up the technology:
NOTICE
Risk of collision
Value changes of SD42940, SD42942 and SD42950 during the program execution can cause
collisions. Only set the setting data during the commissioning.
SD42935 $SC_WEAR_TRANSFORM Transformations for tool components
= 1 Orientation for milling tools: Standard
G group 56: Observe or set TOWWCS
Technologies and cycles
21.8 Turning on milling machines
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 601
